category | Item | The Product parameters | |||||||
Min | Typ | Max | Units | ||||||
Electrical parameters | Input Voltage(50HZ) | 160 | 220 | 265 | V(AC) | ||||
DCInput Voltage | 7 | 12 | 28 | V(DC) | |||||
Driving voltage | 7 | 12 | 28 | V(DC) | |||||
Output Power | -- | 55 | 60 | W | |||||
Operating Temperature | -20 | 25 | 65 | ℃ | |||||
Power factor | -- | 0.65 | 0.7 | ||||||
Other's parameters | Overall dimensions | 110*80*32mm | |||||||
The product weight | 90g | ||||||||
Control Mode | Simulation speed+IR | ||||||||
Drive Method | FOC | ||||||||
The Producs features | 1. Good stability. Using Fortiortech dual-core scheme, driving algorithm hardware solidification, more stable operation | ||||||||
2. Long service life.Use imported or big brand components, stable quality. | |||||||||
3. High applicability of motor. For single brushless DC motor below 60W, the driving mode can be set according to customer requirements 。 | |||||||||
4. Low energy consumption. The brushless DC motor to the maximum performance, large air volume and less power consumption. | |||||||||
Suitable Scope | Suitable Scope widely， Such as: traditional ceiling fans, floor fans and so on...... | ||||||||
